Trine 4850 Low Current Draw Electric Strike - Rim Panic Devices

$354.00

Model:: 4850-42271687

Item is normally in stock and ships out within 3-5 Business days (excluding transit time).

If out of stock it can take up to 2-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

Request for Quote

Email us your RFQ sales@FBIsecurity.com
or call us for pricing 800-523-2924
or send us a request using the form below and we will respond to you by email.

Product Name

Ask A Question

Details: Trine 4850 Low Current Draw Electric Strike - Rim Panic Devices

This low current draw strike is perfect for every day access control system and automatic door installations. The lower current draw allows for a smaller power supply, or allows use of an operator, which saves you money.

The Low Current Draw Solution for Rim Panic Exit Devices Cavity is completely open -- which means the 4850 allows for an incremental depth up to a 1" throw.

Features

4850PoE - .260 Amps @ 12DC uses 3.12 Watts.
Power over Ethernet (PoE) systems are growing more popular, be prepared!
4850LCD - .135 Amps @ 24DC uses 3.24 Watts.
Comes with Trines Patented 6-Pin Anchoring System.
Fail-safe/Fail-secure (field selectable).
BHMA Grade 1 Electric Strike -- 1,000,000+ Life cycles -- 1,500+ lbs. Holding Force
No cutting of the frame.
1/2" thick Surface Mount that comes with a 1/4" and a 1/8" Spacer -- this provides the flexibility of up to 4 different sizes!
Reduce the number of installations that need a separate power supply for door hardware or add more devices to your system.
Increase UPS up time due to lower current draw.
Cavity is completely open -- which means the 4850 allows for an incremental depth up to a 1" throw -- competitor backplates do not allow for this versatility.
Contains a one piece locking mechanism with one Solenoid -- less parts mean less problems.

Specifications

Lower Temperature Rating: -20°C
Maximum Temperature: 40°C
Voltage: 24DC
Country of Origin: America
Warranty: 2 Year Limited Warranty (Axion)

Electrical Characteristics

Voltage	Amps	Watts	Duty	Sound
12DC	0.260	3.12	Intm./Cont.	Silent
24DC (only)	0.135	3.24	Intm./Cont.	Silent

Downloads

4850 Dimensions

Trine's very low current draw electric strike that can be used with PoE (Power over Ethernet) devices. Low Current Draw ™ electric strikes use less then 300 Milliamps (.300 Amps) or around 3.6 - 3.7.Watts to activate.

This provides plenty of "cushion" for PoE based access control systems, room to run longer wires, or extra amps to run additional devices. An electric strike of this variety does not come with an Ethernet port as a remote activation like that would rarely be used and not how such a devices is commonly used.

List of Low Current Draw ™ Electric Strikes:

Strike	Features
4100-One Box Solution	.240 Amps @ 12DC uses 2.88 Watts \|\| .114 Amps @ 24DC uses 2.74 Watts.
4850PoE	.260 Amps @ 12DC uses 3.12 Watts.
4850LCD	.135 Amps @ 24DC uses 3.24 Watts.
The Entire EN Series	The only UL Outdoor Rated Strikes which include the popular EN400 for Cylindrical and Mortise Locks and the EN400RP for Rim Panic Exit Devices. All strikes are -- .280 Amps @ 12DC uses 3.36 Watts & .150 Amps @ 24DC uses 3.6 Watts

1. Easy Install

Traditionally, to use an electric strike on a PoE system a second power supply had to be run. With a Low Current Draw ™ electric strike, this is no longer necessary. It will run fromth power provided through the access control system. These electric strikes provide a power cushion which can be used any way you need.

2. Smaller Power Supplies

Low Current Draw ™ means you can use smaller power supplies and save some green. It's also peace of mind, knowing that you won't need to worry about power supply size problems or issues with amperage drop. Make your everyday installations hassle free.

Lockset Strike Recommendations
Name		Recommended Choices
Cylindrical Lock		4100, 4200, 400CMRP, 234X-375, 234, 478X-375, 478, 258, 258RD, 458
Mortise with a Deadbolt		4100DBDL
Mortise Lock		4100, 400CMRP
Mortise Lock		4100, 4200
Dead Latch		4100, 4200, 258, 258RD, 458
Vertical Rod Latch		275VR
Mortise Exit Device		4100, 400CMRP
Rim Panic Exit Device		4850, 4850PoE, 4850LCD, 4800F, 4801, 400CMRP

Electric Strikes & Compatible Door Frames
Electric Strike	Compatible Door Frames	Notes
4100	Hollow Metal Frame, Wood, Aluminum	Use the 4100RX for Raco© frames (covers the extra 1/4" gap in the frame)
4100DBDL	Hollow Metal Frame, Wood, Aluminum	Best strike for allowing deadbolt privacy with an override.
4200	Wood, Aluminum	ONLY strike with Fascia Color Options -- Match the Fascia to your frame!
4850, 4850PoE, 4850LCD	Hollow Metal Frame, Wood, Aluminum	For wood frames use 2" long mounting screws.
4800F, 4801	Hollow Metal Frame, Wood, Aluminum	For wood frames use 2" long mounting screws.
400CMRP	Hollow Metal Frame, Wood	For wood frames use 2" long mounting screws.
275VR	Hollow Metal Frame, Wood, Aluminum	2-3/4" wide plate. Fits in tight spots in the header.
234X-375	Formed Sheet Metal, Wood	For wood frames use 2" long mounting screws.
234	Hollow Metal Frame, Wood	For wood frames use 2" long mounting screws.
478X-375	Formed Sheet Metal, Aluminum, Wood	For wood frames use 2" long mounting screws.
478	Hollow Metal Frame, Wood
258, 258RD	Aluminum
458	Aluminum
